Rapamycin

Example 01

lets display Rapamycin

;; Blender Import and Basimol Import
(import bpy)
(import IPython)
(require '[basimol.core :as bc])

;; setup the scene. we will save to a file.
(set! (.. bpy -context -scene -render -image_settings -file_format) "PNG")
(set! (.. bpy -context -scene -render -filepath) "/tmp/output.png")
(bc/clear-objects)

;; define materials and selections and then put it all together
(let [
    ;; styles for materials. its Just data....
    surface_params {
        "Emission Strength" 0.5
        "Alpha" 0.25}
    cartoon_params {
        "Emission Strength" 0.0
        "Alpha" 0.5}
    sticks_params {
        "Base Color" [0.15 1 0.15 1]
        "Emission Strength" 3
        "Emission Color" [0.15 1 0.15 1]}

    ;; styles for components
    style_overrides
        {:ball+stick
            {"Quality" 2
            "As Mesh" true
            "Sphere Radii" 0.4
            "Bond Split" false
            "Bond Find" false
            "Bond Radius" 0.4
            "Color Blur" false
            "Shade Smooth" true}
        :cartoon {
            ;"DSSP" true
            "Loop Radius" 1.1}}

    ;; camera location/view.
    ;; from (bc/get-view)
    view  [
        [0.28517988324165344 0.384846031665802 -0.877818763256073 -1.7708362340927124]
        [-0.958473801612854 0.11450467258691788 -0.2611822485923767 -0.5268866419792175]
        [-7.748600978629838e-07 0.9158504009246826 0.4015194773674011 0.8099910020828247]
        [-0.0 0.0 -0.0 1.0]]

    surface_material (bc/create-basic-material (str (gensym)) (merge bc/bsdf-principled-defaults surface_params))
    cartoon_material (bc/create-basic-material (str (gensym)) (merge bc/bsdf-principled-defaults cartoon_params))
    sticks_material (bc/create-basic-material (str (gensym)) (merge bc/bsdf-principled-defaults sticks_params))

    arr  (bc/load-pdb "1fap")
    ligand (bc/filter-resname arr "RAP")
    struct_lig (aget arr ligand)]

    ;; draw and position
    (bc/draw! arr :cartoon style_overrides  cartoon_material)
    (bc/draw! struct_lig :ball+stick style_overrides sticks_material)
    (bc/draw! arr :surface {} surface_material)
    (bc/set-view! view)

    (bpy.ops.render/render **  :write_still true))

;; for ipython display
(IPython.display/display
    (IPython.display/Image "/tmp/output.png"))
